850MHz to 940MHz 10 dBi 120 Degree Sector Antenna for ISM, GSM, LoRaWAN IoT, SigFox and Wireless LAN Systems. It is ideally suited for multipoint, Non Line of Sight (NLOS) IoT and 900MHz mobile applications where high gain and wide coverage is desired. This antenna features a integral N-Female type connector. Also included with this Sector Antenna is a dual mast mounting kit, consisting of a heavy-duty stainless steel pole mount brackets, this kit allows installation on masts up to 75 mm in diameter.
Features
- Suitable for LoRaWAN and Sigfox 865MHz, 868MHz and 915MHz, 923MHz IoT applications
- Sealed Fiberglass Radome, Strong Protection against the elements
- All Weather Operation
- Stable Steel Mounting Kit
| Details | |
|---|---|
| Manufacturer's Product Code | ANT-280 |
| Frequency Range | 850MHz to 940MHz |
| Polarization | Vertical Single Polarisation |
| Gain | 10dBi |
| Electrical Downtilt | 0 Degrees |
| Half-power beam width | Horizontal: 120deg, Vertical: 27 deg |
| Front-to-back ratio | above 18dB |
| Impedance | 50 Ohm |
| VSWR | Lower than1.5 |
| Maximum power | 500W |
| Lighting protection | DC Ground |
| Connector | N Female |
| Connector position | Bottom |
| Height/width/depth | 650mm × 270mm × 137mm |
| Packing size | 750mm × 350mm × 250mm |
| Weight | 5.5Kg |
| Radome material | UPVC |
| Radome colour | Gray |
| Mechanical tilt | 0~10 degrees |
| Operating temperature | -40~60 degC |
| Rated wind velocity | 60 m/s |
| Suitable pole diameter | 50~75 mm |
| Mounting kit | Dual Stainless Steel Pole Mount |
| Details | |
|---|---|
| Pole Mount | Included |
LoRAWAN , Proprietary
N-Type
600-999MHz
