Cambium ePMP 5 GHz Force 4518 Integrated 18dBi Subscriber Module and PTP Radio

$280.00 +GST

10 In Stock

SKU: C050940C831

Quantity	Price
1 - 4	$280.00
5 - 9	$273.00
10 - 19	$266.00
20+	$252.00

Data Sheet

Cambium ePMP 5 GHz Force 4518 SM Radio (ROW) (ANZ cord)

Warranty

Back to: Wireless Systems

Same day dispatch for orders placed before 3pm (NZDT), Free shipping on all orders $1000+GST*

Description

Specifications

Resources

Package Contents

Cambium ePMP 5 GHz Force 4518 Integrated 18dBi Subscriber Module and PTP Radio.

Service providers face ever-increasing demand for capacity in a limited amount of spectrum. The ePMP Force 4518 Subscriber Modules (SM) meet this demand by offering high performance and low latency across both point-to-multipoint (PMP) and point-to-point (PTP) deployments.

Features

Small form factor popular for dense areas and where aesthetics are critical, with an integrated 18 dBi panel antenna
High performance with up to 80 MHz channels, 1024QAM and low-latency performance when using ePTP technology
Interoperability with the ePMP 4500, which uses MUMIMO to achieve up to multiple Gbps per sector by transmitting to 3 ePMP 4500 SMs simultaneously
Multiple levels of QoS (Quality of Service) for voice, video, and data applications, supporting a wide variety of service packages for both residential and enterprise users
Security features meeting the requirements of enterprise, industry, government, and service provider users
Management by Cambium Networks cnMaestro™ network management system for easy provisioning, monitoring, and upgrades
Network planning with LINKPlanner and cnHeat
Cambium Networks’ 3-year hardware warranty and support
Includes Power over Ethernet (PoE) injector and pole mount hardware

Details
Product Code	C050940C831A
Channel Width	MHz 20 / 40 / 80 MHz
Proprietary Physical Layer	2x2 MIMO/OFDMA
Channel Spacing	Configurable in 5 MHz increments
Frequency Range	Wide band operation 5150–5920 MHz (Allowable frequencies and bands are dictated by individual country regulations)
MAC Layer (Media Access Control)	Cambium proprietary
Ethernet Interface	100/1000 BaseT, compatible with Cambium PoE & standard PoE pinouts
Protocols Used	IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
Network Management	IPv4/IPv6, HTTPs, SNMPv2c, SSH, cnMaestro
VLAN	802.1Q with 802.1p priority
ARQ	Yes
Nominal Receive Sensitivity (w/FEC) @20 MHz Channel	MCS 1 = -84 dBm to MCS 11 (1024 QAM-5/6) = -53 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel	MCS 1 = -82 dBm to MCS 11 (1024 QAM-5/6) = -52 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @80 MHz Channel	MCS 1 = -80 dBm to MCS 11 (1024 QAM-5/6) = -50 dBm (per chain)
Modulation Levels (Adaptive)	MCS 1 (QPSK) to MCS 11 (1024 QAM5/6)
Transmit Power Range	+3 to +28 dBm (combined, to regional EIRP limit) (1 dB interval)
QoS (Quality of Service)	Three level priority (voice, high, low) with packet classification by DSCP, COS, VLAN ID, IP & MAC address, broadcast, multicast and station priority, MIR/CIR* support
Surge Suppression	1 joule integrated
Environmental	IP55
Temperature	-30°C to 55°C (-22°F to 131°F)
Weight	TBD
Wind Survival	TBD
Dimensions (Dia x Depth)	180 x 210 x 39 mm (7.08 x 8.27 x 1.54 in)
Pole Diameter Range	Center: 3.1 to 7.6 cm (1.25 to 3.0 in)
Power Consumption	13W
Input Voltage	Passive PoE 27–59V
