Milesight 5MP AI TrafficX IP Camera

$5,200.00 +GST
Login for your price
1 In Stock
SKU: TS5510-GH
QuantityPrice
1 - 4$5 200.00
5 - 9$4 810.00
10 - 19$4 680.00
20+$4 420.00
Milesight 5MP AI TrafficX IP Camera
Warranty
Same day dispatch for orders placed before 3pm (NZDT), Free shipping on all orders $1000+GST*
Supported Platforms
vGRID
Description
Specifications
Resources
Package Contents
The Milesight TrafficX IP Camera Seize every moment in pristine clarity! With global shutter technology, all pixels are exposed simultaneously, allowing for the accurate capture of fast-moving vehicles, eliminating motion blur, distortions and providing crystal-clear images for accurate analysis.

Say hello to hassle-free traffic monitoring! With AI-based ANPR on the edge, our TrafficX camera achieves unmatched accuracy in identifying vehicles. Identify license plates, plate colors, vehicle types, brands, colors - all effortlessly.

Elevate recognition with the Milesight TrafficX Camera – a true marvel! The camera expertly manages a wide range of plate types, guaranteeing flexibility in any situation. Frame Parity Flashing technology enables camera to take several images of the vehicle, ensure the clear capture of reflective & non-reflective plates and provide the most accurate results of vehicle and plate recognition. Recognizing high-contrast license plates has never been a problem, but recognizing low-contrast license plates can be very challenging, especially at night. And that's where we shine. Introducing our game-changing 740nm infrared wavelength technology (optional) – a brilliant innovation for effortlessly capturing those elusive, low-contrast license plates with unparalleled clarity.

Effortless integration with your existing systems is guaranteed. Milesight TrafficX Camera supports CGI/APIs and TCP/HTTP/MQTT protocols for easy integration. Furthermore, it provides edge storage of up to 1TB on an SD card, ensuring powerful data storage and access. Operators are often overloaded with the massive video and data, and the smart forensic evidence ensures that the operator is always on the right track when searching for the corresponding clips, greatly facilitating investigations and speeding up case resolution.

Covering a 50m ANPR distance, Milesight TrafficX Camera monitors 2-3 lanes simultaneously, ensuring extensive coverage for streamlined traffic management. With multiple installation methods, including Pedestal Mount, Pedestal Pole Mount, Wall Mount and Wall Pole Mount as well as flexible angle adjustment, the camera is freely installed in the middle of the road or on the side of the road.
Features
  • High-performance AI Chip and AI ISP Embedded
  • AI-based Onboard ANPR
  • 250km/h High Recognizable Speed
  • 99% Capture Rate & 98% Plate Recognition Rate
  • 2*5MP Auto Focus Lenses
  • Dual-lens for Overview and ANPR Image
  • 50m ANPR Distance & 2-3 Lanes Covering
  • Support 1TB SD Card for Edge Storage
  • 4G LTE Network for Wireless Transmission (Optional)
  • Built-in GPS for Precise Location
  • vGRID SaferCity Platform Compliant
Details
Product CodeTS5510-GH
Product Name5MP TrafficX Camera
Min. IlluminationColor: 0.001 Lux@(F1.4, AGC ON)
Shutter Time30 us- 40000 us
Day/Night ModeDay/Night/Auto
Supplement LightIR: IR Strobe Light (16 light beads) IR Distance: 60m IR Wave Length: 850nm (Default), 740nm (Optional)
Max. ANPR RangeUp to 50m
Max. Vehicle Speed250 km/h
CoverageRecommended for 2~3 lanes
Capture RateUp to 99%
Recognition AccuracyUp to 98%
Country Region SupportedMore than 74 countries and regions
Attributes IdentificationPlate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture
Violation ManagementReverse Driving, Vehicle Attributes Event Detection
White/Black ListUp to 2000 records inside the camera
LPR Smart SearchSupport
Lens15-50mm, Motorized zoom and focus
MountCustom mount
Field of Viewhorizontal FOV 41.4° to 10.3°, vertical FOV 26.8° to 8.42°, diagonal FOV 32° to 13.3°
Ethernet1*RJ45 10M/100M/1000M Ethernet Port
RS485Support
Input4 * Optoisolated Input
Output2 * Strobe Output, 1 * Relay Output
Max. Resolution2464x2056
Max. FPS30fps
Video CompressionH.265/H.264/MJPEG
Video Bit Rate16Kbps~16Mbps (CBR/VBR Adjustable)
Image SettingBrightness/Contrast/Saturation
Privacy MaskingUp to 24 Areas (per Sensor)
System CompatibilityAPI, HTTP, TCP, MQTT, ONVIF Profile G & S & T
StorageSupport microSD/SDHC/SDXC Card Local Storage, up to 1TB
GPSBuilt-in High-accuracy GPS Module
Working Temperature-40°C ~ 70°C
Working Humidity0~95% (Non-condensing)
Power Consumption22W MAX 26W MAX (With IR on)
Weather ProofUp to IP67-rated for Weather-resistant Performance
Power Supply24 V DC/AC
Weight4.3Kg
Dimensions121mmx295mmx245mm(Without Mounting Bracket)
Warranty3 Years
Details
ContentsWarranty card, QSG, Wall mount, mounting screws and tightening tool included
Power SupplyNot included
vGRID
100Mbps
RJ45
DC 12V/2A , PoE (802.3af/at) , POE+ (802.3at)
