Ubiquiti UniFi Dream Machine 802.11ac 4x4 4 Port Switch and Controller

UDM
SKU: UDM
Ubiquiti UniFi Dream Machine 802.11ac 4x4 4 Port Switch
Ethernet Speed
1Gbps
Frequency Category
2.4GHz , 5GHz
Wireless Technology
802.11a , 802.11b , 802.11g , 802.11n , 802.11ac
Warranty:
In stock
Description
Description
Specifications
Resources
Package Contents
The Ubiquiti UniFi Dream Machine (UDM)is powered by a fast 1.7 GHz quad-core processor and combines multiple functions into a single elegant device. The UDM with its built in UniFi controller is the easiest way to introduce UniFi 802.11ac 4x4 Wi-Fi to homes and businesses. The UDM includes everything you need for a small-scale wired or Wi-Fi network. It's easy to use and still offers all the benefits of UniFi for homes and businesses.

The centralized management software featuring a graphical user interface offers easy setup and convenient control. The UniFi Dream Machine offers advanced firewall policies and persistent threat management to act as an Intrusion Prevention System (IPS) and Intrusion Detection System (IDS).
Features
  • High-Performance Dual Band 802.11ac 4x4 Wave 2 Access Point
  • Managed 4-Port Gigabit Switch
  • Advanced Security Gateway with IDS/IPS and DPI
  • Integrated UniFi Network Controller with Intuitive User Interface
  • Scalable Through Additional UniFi Devices Connected to LAN
  • Powered by Fast 1.7 GHz Quad-Core Processor
  • UniFi cloud remote management
Details
Manufacturer's CodeUDM
Dimensions110 x 184.2 mm (4.33 x 7.25")
Weight1.05 kg (2.32 lb)
Networking Interfaces(4) LAN 10/100/1000 RJ45 Ports, (1) WAN 10/100/1000 RJ45 Port
ButtonsReset
IDS/IPS Throughput1 Gbps
ProcessorArm Cortex-A57 Quad-Core at 1.7 GHz
System Memory2 GB DDR RAM
On-Board Flash Storage16 GB
Maximum Power Consumption26W
Supported Voltage Range100 - 240VAC
Power MethodAC Power Cord
Power SupplyInternal AC/DC Power Adapter (24V, 0.6A, 100 - 240VAC)
Power SaveSupported
BeamformingSupported
TX Power2.4 GHz - 23 dBm, 5 GHz - 26 dBm
Antenna(1) Dual-Band, Quad-Polarity Antenna
Antenna Gain2.4 GHz - 3 dBi, 5 GHz - 4.5 dBi
Wi-Fi Standards802.11 a/b/g/n/ac/ac-wave2
Wireless SecurityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
BSSIDUp to 8 per Radio
Operating Temperature-10 to 45° C (14 to 113° F)
Operating Humidity5 to 95% Noncondensing
CertificationsCE, FCC, IC
Details
Power CordIncluded
