Grandstream GWN7664ELR 4x4 802.11ax WiFi 6 Outdoor Long Range AP, AX6000, 1 x 2.5 Gbe + 1 x 2.5 SFP Ports, HE160, Bluetooth, Integrated Antenna
The GWN7664ELR is a high-performance outdoor long-range 802.11ax Wi-Fi6 access point for medium-to-large businesses and enterprises who need to provide long-range coverage in outdoor spaces. It offers IP67-level weatherproof capability, dual-band 4×4:4 MU-MIMO with OFDMA technology and a sophisticated antenna design for up to 6 Gbps wireless throughput that supports 512 clients and an expanded 300-meter coverage range.
To ensure easy installation and management, the GWN7664ELR includes a built-in controller embedded within the product’s web user interface. It is also supported by GWN.Cloud and GWN Manager, Grandstream’s free cloud and on-premise Wi-Fi management platform. The GWN7664ELR is the ideal Wi-Fi AP for voice-over-Wi-Fi deployment and offers a seamless connection with Grandstream’s Wi-Fi capable voice and video IP phones. This device features support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 2.5 Gigabit Ethernet port with PoE+, and a 2.5 Gigabit SFP port. TheGWN7664ELR is an ideal outdoor Wi-Fi access point for enterprises, multiple floor offices, warehouses, hospitals, schools and more.
The GWN7664ELR is a high-performance outdoor long-range 802.11ax Wi-Fi6 access point for medium-to-large businesses and enterprises who need to provide long-range coverage in outdoor spaces. It offers IP67-level weatherproof capability, dual-band 4×4:4 MU-MIMO with OFDMA technology and a sophisticated antenna design for up to 6 Gbps wireless throughput that supports 512 clients and an expanded 300-meter coverage range.
To ensure easy installation and management, the GWN7664ELR includes a built-in controller embedded within the product’s web user interface. It is also supported by GWN.Cloud and GWN Manager, Grandstream’s free cloud and on-premise Wi-Fi management platform. The GWN7664ELR is the ideal Wi-Fi AP for voice-over-Wi-Fi deployment and offers a seamless connection with Grandstream’s Wi-Fi capable voice and video IP phones. This device features support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 2.5 Gigabit Ethernet port with PoE+, and a 2.5 Gigabit SFP port. TheGWN7664ELR is an ideal outdoor Wi-Fi access point for enterprises, multiple floor offices, warehouses, hospitals, schools and more.
Features
- 6Gbps aggregate wireless throughput, 2.5Gbps RJ45 and 2.5Gbps SFP wireline ports
- Dual-band 4×4:4 MU- MIMO WiFi6 with OFDMA technology
- MediaTek Wi-Fi Chipset
- 2.5 Gigabit Ethernet Port supports self power adaptation upon auto detection of PoE+
- Supports 512 concurrent Wi-Fi client devices
- Up to 300-meter coverage range
- Advanced QoS to ensure real-time performance of low-latency applications
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Flexibility of 8 internal antennas
- Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management
| Details | |
|---|---|
| Manufacturer's Code | GWN7664ELR |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Antennas | 8 individual internal antennas, 4 per band; 2.4GHz, gain 3.5dBi, 5 GHz, gain 4.5dBi |
| Wi-Fi Data Rates Max | 5GHz: IEEE 802.11ax: 7.3 Mbps to 4804 Mbps, 2.4GHz: IEEE 802.11ax: 7.3 Mbps to 1147 Mbps |
| Frequency Bands | 2.4GHz Radio: 2400 - 2483.5 MHz, 5GHz Radio: 5150 - 5895 MHz |
| Channel Bandwidth | 2.4GHz: 20 and 40 MHz x 4, 5GHz: 20, 40, 80 and 160 MHz x 4 |
| Wi-Fi and System Security | WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| MU-MIMO | 4×4:4 2.4GHz, 4×4:4 5GHz |
| Coverage Range | Up to 300 meters *coverage range can vary based on environment |
| Maximum TX Power | 5GHz: 23.5dBm, 2.4G: 24.5dBm *Maximum power varies by country, frequency band and MCS rate |
| Maximum RX Sensitivity | 2.4GHz -97dBm, 5GHz -93dBm |
| SSIDs | 32 SSIDs total, 16 per radio (2.4GHz & 5GHz) |
| Concurrent Clients | 512 |
| Network Interfaces | 1x 2.5G RJ45 Port and 1x 2.5G SFP Port |
| Auxiliary Ports | 1x Reset Pinhole |
| Mounting | Wall mount or pole mount, kits included (The mounting kits can be rotated and adjusted by 60°) |
| LEDs | 1 tri-color LEDs for device tracking and status indication, 1 single-color LED for SFP indication |
| Network Protocols | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| QoS | 802.11e/WMM, VLAN, TOS |
| Network Management | Embedded controller can manage up to 50 local GWN APs, GWN.Cloud offers a free cloud management platform for unlimited GWN APs, GWN Manager offers premise-based software controller for up to 3,000 GWN APs |
| Power and Green Energy Efficiency | PoE 802.3at; Maximum Power Consumption: 24W |
| Environmental | Operation:-30°Cto 60°C, Storage: -30°C to 60°C, Humidity: 10% to 90% Non-condensing |
| Physical | Unit Dimension: 260mm(L)x310mm(W)x59mm(H); Unit Weight: 1.445kg, Entire Package Dimension: 469mm x 377mm x 137mm; Entire Package Weight: 3.06kg |
| Weatherproof Grade | IP67-level weatherproof capability |
| Compliance | FCC, CE, RCM, IC |
| Details | |
|---|---|
| Package Content | GWN7664ELR 802.11ax Wireless AP, Mounting Kits, Quick Installation Guide |
