Milesight 16-Channel is compliant with the NDAA (National Defense Authorization Act). It does not use or deploy critical components including SoCs produced by NDAA banned component vendors, which is recommended for enterprises and critical applications where compliance is essential.
Defined as the Enterprise ANPR management system, Milesight NDAA 4K H.265 Pro NVR 5000 Series becomes the central management site to easily monitor the traffic, including the real-time preview of the car plates, smart analysis and other more detailed settings. Defined as the central management site to manage intelligent VCA，it supports alarm configurations and event search of Milesight AI VCA. Once suspicious events detected, the device can trigger alarms and recordings, helping improve video surveillance efficiency.
The combination of retail transaction data with surveillance videos makes it easy to check goods settlement, miscalculation and missing calculation in the stores, supermarkets and other places, which is helpful to boost customer service and in-store competitive advantage.
ANR can store video data on the camera storage card when network between IPC and NVR is disconnected and retransfer the recorded video to NVR after network recovers.
Flexible storage options including HDD and NAS in Milesight NDAA 4K H.265 Pro NVR 5000 Series offer you greater flexibility to address the needs for versatile storage The preview of the multi-channel videos via all major browsers without downloading extra plug-in is realized when Video Codec is set to H.265, making it easy for users to access the NVRs. Milesight NDAA 4K H.265 Pro NVR 5000 Series comes with a whole array of ports such as an HDMI port, a VGA port, Alarm I/O, Audio I/O and a LAN port, etc. The full set of interfaces provides all necessary features for effective surveillance.
*Please Note: HDDs need to be purchased separately
Defined as the Enterprise ANPR management system, Milesight NDAA 4K H.265 Pro NVR 5000 Series becomes the central management site to easily monitor the traffic, including the real-time preview of the car plates, smart analysis and other more detailed settings. Defined as the central management site to manage intelligent VCA，it supports alarm configurations and event search of Milesight AI VCA. Once suspicious events detected, the device can trigger alarms and recordings, helping improve video surveillance efficiency.
The combination of retail transaction data with surveillance videos makes it easy to check goods settlement, miscalculation and missing calculation in the stores, supermarkets and other places, which is helpful to boost customer service and in-store competitive advantage.
ANR can store video data on the camera storage card when network between IPC and NVR is disconnected and retransfer the recorded video to NVR after network recovers.
Flexible storage options including HDD and NAS in Milesight NDAA 4K H.265 Pro NVR 5000 Series offer you greater flexibility to address the needs for versatile storage The preview of the multi-channel videos via all major browsers without downloading extra plug-in is realized when Video Codec is set to H.265, making it easy for users to access the NVRs. Milesight NDAA 4K H.265 Pro NVR 5000 Series comes with a whole array of ports such as an HDMI port, a VGA port, Alarm I/O, Audio I/O and a LAN port, etc. The full set of interfaces provides all necessary features for effective surveillance.
*Please Note: HDDs need to be purchased separately
Features
- ONVIF Compatible
- Up to 20TB capacity (HDDs purchased separately)
- Decode up to 2-CH 4K UHD & 8-CH 1080P
- ANR
- Supports Dual Streaming
- 4K Streaming
- HDMI Out
- Versatile Interfaces
- P2P
- VCA
- NDAA
| Details | |
|---|---|
| Network Video Input | 16-CH |
| Bandwidth Requirement | 160Mbps (Incoming), 160Mbps (Outgoing) |
| HDMI Output | 1-CH, Resolution: 3840x2160/30 Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI Supports Audio Output |
| VGA Output | 1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz. |
| Dual Stream | Support |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/ UXGA/720P/D1/VGA/CIF/QCIF |
| Synchronous Playback | 3*(30fps @8MP), 4*(30fps @6MP),4*(30fps @5MP), 5*(30fps @4MP),8*(30fps @3MP), 12*(30fps @1080P),16*(30fps @720P),16*(30fps @D1) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264 |
| Audio Format | G.711/AAC/G.722/G.726 |
| Sample Rate | 8KHz/16KHz |
| SATA | 2*SATA HDD (3.5”) |
| Capacity | Up to 10TB capacity for each HDD |
| Recording Type | Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) |
| Snapshot Type | Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) |
| Playback Type | General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback |
| Network Protocols | IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS |
| Network Interface | 1*RJ45 10/100/1000Mbps |
| USB Interface | 2*USB 2.0 |
| Audio Input/Output | 1*RCA |
| Alarm Input/Output | 4-CH/1-CH |
| Interface | 16*RJ45 10/100Mbps |
| Power Output | ≤200W |
| Supported Standard | IEEE 802.3af/at |
| Compatibility | ONVIF, API |
| Advanced Function | ANR |
| ANPR | Support |
| Video Analysis | Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting |
| Keyboard Control | Milesight Keyboard(MS-K01) |
| Power Supply | AC 100V∼240V 50Hz∼60Hz |
| Consumption | ≤8.5W(Without HDD, without enabling PoE) |
| Working Conditions | Temperature: -10℃∼+55℃ / Humidity: 10%∼90% |
| Dimensions | 380mm(W)X317.6mm(D)X51.8mm(H), Rack Mountable Chassis(1.0U Standard) |
| Weight | 2.7Kg |
| Warranty | 3 Years |
| Details | |
|---|---|
| Contents | QSG, Mounting hardware, Wall mount, Warranty Card, HDD Bracket |
| Power Supply | Included |
1Gbps
RJ45 , USB
PoE (802.3af/at)
