NEW - Ubiquiti EdgePoint Outdoor S16, EP-S16 Application-specific WISP control point with (16) Gigabit PoE Ethernet ports and (2) 10Gbps SFP+ ports.
Supports both 24V and 54V 2 Paid and 4 Pair PoE. NEW MODEL!
Supports both 24V and 54V 2 Paid and 4 Pair PoE. NEW MODEL!
Features
- 54VDC, 6A Terminal Block with Dual Power input (Terminal Block + PoE Input)
- 16 x Gigabit Ethernet Ports and 2 SFP+ Ports
- PoE Input 54V - 1.5A Passive PoE Input or 54 or 24V, 1.4A Passive PoE
- PoE Output - (4) 54 or 24V, 1.4A 4-Pair or (12) PoE/PoE+ or 24V/0.7A, 2-pair
- Outdoor WISP Applications
- Two 10 Gbps SFP+ Ports
| Details | |
|---|---|
| Manufacturer's Code | EP-S16 |
| Networking interface | (1) RJ45 serial port, (16) 10/100/1000 RJ45 ports, (2) 1/10 Gbps SFP+ ports |
| Power method | (1) DC terminal block, 54V DC, 6A input, *Self-correcting polarity protection on DC terminal block only, diode red protection on all power inputs. |
| Power supply | Min. 54V / 0.8A (Excludes PoE output) |
| Passive PoE input | (2) 54V / 1.5A, 4-pair (+1, 2, 4, 5; - 3, 6, 7, 8) passive PoE, ports 1 and 2, *Do NOT configure port 1 or 2 in PoE output mode if you are using PoE input power sources. |
| Passive PoE output | (4) 54V or 24V /1.4A, 4-pair (+1, 2, 4, 5; - 3, 6, 7, 8) passive PoE, ports 1 to 4, (12) PoE/PoE+ or 24V/0.7A, 2-pair (+ 4, 5; - 7, 8) passive PoE, ports 5 to 16 |
| Power monitoring | (1) DC terminal block, input power, (2) RJ45, ports 1 and 2, PoE input or output power, (14) RJ45, ports 3 to 16, PoE output power |
| Supported voltage range | 42–56V DC (-48V is NOT supported) |
| Max. power consumption | 40W (Excludes PoE output) |
| Button | Factory reset |
| LEDs | System: power, RJ45 ports: speed/link/activity, PoE, SFP ports: speed/link/activity |
| Dimensions | Without wall-mount: 326.6 x 382.7 x 88.8 mm (12.9 x 15.1 x 3.5"), With wall-mount: 326.6 x 382.7 x 105.5 mm (12.9 x 15.1 x 4.2") |
| Weight | Without wall-mount: 3.4 kg (7.5 lb), With wall-mount: 3.8 kg (8.4 lb) |
| Enclosure material | Diecast aluminum alloy, UV-resistant polycarbonate |
| Mount | Pole/wall mount |
| Wind loading | 153 N at 200 km/h (34 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Ambient operating temperature | -40 to 65° C (-40 to 149° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
| Details | |
|---|---|
| Warranty | Standard 12 Month RTB |
1Gbps , 10Gbps
PoE (non standard) , PoE (802.3af/at)
