Cambium 11 GHz PTP 850C Wideband Licensed Microwave Radio (C110085B003).

The Cambium PTP 850C is a next generation all-outdoor, multi-core unit. The PTP 850C has dual-core functionality enabling the system to operate up to 4 Gbps and deliver gigabit-plus capacity.

Note additional hardware and licensing is required for the operation of these radios, please contact us with your link requirements and we can assist with a complete quote.

Features

Operates in the 11 GHz Licensed Band
High Capacity and Spectral Efficiency
4096 QAM Modulation, 40 / 80 MHz
Up to 2+ Gbps @ 80 MHz with XPIC
Field Changeable Diplexer
Multiple 10GE ports
4+0 configuration with Layer 1 aggregation
1+0 to 4+0, XPIC, 1+1/2+2 HSB, E/W
LoS 4x4 MIMO
Advanced Frequency Reuse
Jumbo Frames - Up to 9612 Bytes
PoE Input support on Port 2

Details
Product Code	C110085B003A
Frequency	11 GHz (Diplexer Dependant)
Hardware Configurations	1+0 up to 4+0 Single/Dual Polarization, 1+1/2+2 HSB, 1+1/2+2 HSB-SD, 2+0 XPIC, 2x2+0 East/West Single/Dual Polarization
Ethernet Interfaces	Port 1: DC Port, Port 2: RJ-45 - Electric Multi Rate 1/2.5/10 Gbps traffic interface/PoE port, Port 3: SFP – 1/2.5G traffic interface and Dual band port, Port 4: SFP – 1/10GE traffic interface/MIMO extension port (SFP+), Port 5: SFP – 1/10GE traffic interface (SFP+), Port 6: RJ-45 – Management/Protection interface - 100 Base-T
MTU	9612 Bytes
Ethernet Services	Up to 1024, plus one pre-defined management service
MAC address learning	Up to 64K MAC address
Quality of Service	Multiple Classification criteria (VLAN ID, p-bits, IPv4 DSCP, IPv6 TC, MPLS EXP), 8 CoS queues per port, Deep buffering (configurable up to 64 Mbit per queue), WRED, P-bit marking/remarking
VLAN	add/remove/translate
Management	SNMP, REST, SDN Support: NETCONF/YANG
Synchronization	Enhanced Ethernet Equipment Clock (eEEC) Specification (G.8262.1), PTP Telecom Boundary Clock (T-BC) and Time Slave Clock (T-TSC) Specification (G.8273.2), PTP Telecom Transparent Clock (T-TC) Specification (G.8273.3), Enhanced SyncE Network Limits (G.8261, clause 9.2.1), Enhanced PTP Network Limits (G.8271.1), Ethernet Synchronization Messaging Channel (ESMC) (G.8264, clause 11), PTP Telecom Profile for Time (Full Timing Support) (G.8275.1), Precision Time Protocol (version 2, IEEE1588-2008)
Security	HTTPS, SNMPv3, SSH, SFTP, RADIUS authentication and authorization, TACACS+ Authentication, Authorization, and Accounting (session-based), AES Encryption
Dimensions (Direct Mount)	322mm(H), 227/270mm(W), 86mm(D), 6 kg
Pole Diameter Range (for Remote Mount Installation)	8.89 cm – 11.43 cm
Operating Temperature	-33°C to +55°C (-45°C to +60°C extended)
Power Input Specifications	Standard Input: -48 VDC (DC Input range: -40.5 to -60 VDC)
Power Consumption Specifications	2+0 Operation: 6-11 GHz: 73W, 1+0 Operation (one carrier muted): 6-11 GHz: 63W, Both carrier muted: 6-11 GHz: 38W
