MARS 9dBi 2.3-2.7 & 4.9-5.9 GHz Dual Polarization and Dual Band Omni Directional Antenna. This Dual Band Antenna provides a stable and efficient performance with 7.5 -9 dBi of gain and cost effective solution for large scale applications and systems such as 802.11, Point To Multi Point ,WLAN access points, mesh Networks, ISM, WiMAX and more.
Features
- Dual Band 2.4GHz, 5GHz and Dual Polarised!
- Wide Band frequency usage
| Details | |
|---|---|
| Manufacturer's Product Code | MA-WO2556-DPDB9 |
| Frequency Range | 2.3 -2.7 GHz and 4.9-5.9 GHz |
| GAIN, typ | 7.5 dBi @ 2.4GHz, 9 dBi @ 5GHz |
| VSWR typ | 1.7 :1 |
| VSWR, max | 2.55 : 1 |
| Polarization | dual pol - Vertical & Horizontal |
| 3 dB Beam-Width, Azimuth, typ | 360 degrees |
| 3 dB Beam-Width, Elevation, typ | 22° @ 2.4GHz, 11° @ 5GHz |
| Input power, max | 10 Watt |
| Port to Port Isolation, typ | 30 dB |
| Port to Port Isolation, min | 25 dB @ 2.4GHz, 20 dB @ 5 GHz |
| Input Impedance | 50 Ohm |
| Lightning Protection | DC Grounded |
| Dimensions (ØxH) | 970 x 70 mm (38.2" x 2.75") |
| Weight | 1.1 Kg. |
| Connector | 4 x N-Type, Female |
| Radome | UV Protected Plastic |
| Mount | 2 inch Pole Mount |
| Operating Temp Range | -40°C to +65°C |
| Wind Load | 200 km/h (survival) |
| Vibration | According to IEC 60721-3-4 |
| Flammability | UL94 |
| Water Proofing | IP-65 |
| Salt Fog | According to IEC 68-2-11 |
| Humidity | ETS 300 019-1-4, EN 302 085 (annex A.1.1) |
| Details | |
|---|---|
| Pole Mount | Yes, Included |
| Warranty | Standard 12 Month RTB |
N-Type
2.4GHz , 5GHz
