The Ubiquiti NanoStation M2 is the perfect solution for creating a dedicated Point to Point or Point to Multipoint connection between locations where running an Ethernet cable is not a viable option. The Ubiquiti NanoStation M2 can also be used for extending long range wireless coverage outdoors or to remote buildings to provide direct Wi-Fi access to mobile devices. The original Ubiquiti NanoStation set the bar for the world's first low-cost and efficiently designed outdoor broadband CPE. The new Ubiquiti AirMax NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors. Real high speed outdoor wireless throughput and up to 10km+ range. Featuring 2x2 MIMO wireless technology, the new NanoStation links significantly faster and farther than ever before.
Features
- Next-Gen Antenna Design: New Ubiquiti antenna array designs featuring 11dBi dual-polarity gain at 2.4GHz with optimized cross-polarity isolation and in a compact form-factor.
- Dual Ethernet Connectivity: The New NanoStation M provides a secondary ethernet port with software enabled POE output for seamless IP Video integration.
- Intelligent POE: Remote hardware reset circuitry of NanoStation M allows for device to be reset remotely from power supply location. In addition, any NanoStation can easily become 802.3af 48V compliant through use of Ubiquiti's Instant 802.3af adapter.
- AirOS V: Ubiquiti's AirOS builds upon the market leading intuitive user-interface loaded with advanced wireless configurations and routing functionality.
| Details | |
|---|---|
| Manufacturer's Code | NSM2 |
| Output Power | 28 dBm |
| Operating Modes | AP/Station/WDS |
| Frequency Range | 2412 - 2472 MHz |
| Interfaces | (2) 10/100 Ethernet Ports |
| Wireless standards | 802.11b/g/n |
| Temperature Range | -30 to 75° C |
| PoE In | Yes, 12-24V |
| PoE Out | PoE Passthrough (Requires 24V1A PoE Injector) |
| Operating System | Ubiquiti airOS V |
| Antenna gain dBi | 11 dBi |
| Max Power consumption | 8 W |
| Polarisation | Dual Linear |
| Beamwidth | 55° (H-pol) / 53° (V-pol) / 27° (Elevation) |
| Maximum Range | up to 10km+ line of sight |
| Pole Diameter | 30-50mm |
| Details | |
|---|---|
| Power Supply | 3 Pin Clover Lead |
| Power Injector | 24V POE Injector |
| Pole Mount | Yes, Hose Clamp or Cable Tie |
| Wall Mount | Optional - Purchased Separately |
| Window Mount | Optional - Purchased Separately |
100Mbps
Wi-Fi 4 , Proprietary
2.4GHz
PoE (non standard)
